74 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Digital Inputs, continued
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P3.12 1020 — PID controller deactivate 6
Like P3.2 Allocation of the function to control signal terminals
When switching on +24V power, the PID controller is
blocked via the assigned control signal terminal (DI1 to DI6)
P3.13 1400 — — (Not used) —
P3.14 1401 — External brake, feedback signal (N/O) 0
Like P3.2 Assignment of control signal terminal
P3.15 1402 — Change acceleration/deceleration time (acc 2/dec 2) 0
Like P3.2 Assignment of control signal terminal
Switch acceleration time from acc1 (P6.5) to acc2 (P6.19)
Switch deceleration time from dec1 (P6.6) to dec2 (P6.20)
P3.16 1403 — Stop acceleration/deceleration time 0
Like P3.2 Assignment of control signal terminal
Stops all acceleration (P6.5, P6.19, P14.9) and deceleration
times (P6.6, P6.20, P14.10)
P3.17 1404 — Block parameter access 0
Like P3.2 Assignment of control signal terminal
Blocks access to all parameters
Note: The resetting of all parameters to the default settings
via the STOP button (held down 5s) remains active
P3.18 1405 — Motor potentiometer, increase value
Acceleration time, see “P6.5” (acc1)
0
Like P3.2 Assignment of control signal terminal
P3.19 1406 — Motor potentiometer, decrease value
Deceleration time, see “P6.6” (dec1)
0
Like P3.2 Assignment of control signal terminal
P3.20 1407 — Motor potentiometer, set value to zero 0
Like P3.2 Assignment of control signal terminal
P3.21 1408 — PLC program start 0
Like P3.2 Assignment of control signal terminal
