Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 75
Digital Inputs, continued
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P3.22 1409 — PLC program pause 0
Like P3.2 Assignment of control signal terminal
Pause will occur in between steps of the PLC program until
control signal is removed
P3.23 1410 — Counter, input signal 0
Like P3.2 Assignment of control signal terminal
Counts the activation of the selected digital input (DI1–DI6)
P3.24 1411 — Counter, reset 0
Like P3.2 Assignment of control signal terminal
Resets the outputs P5.1–P5.3 = 20 and/or 21 and display value
M1.21 to zero
P3.25 1412 — Activate secondary remote control source 0
Like P3.2 Assignment of control signal terminal
Move between the control levels set at P6.1 and P6.17
(LOC-REM function)
P3.26 1413 — Activate secondary remote speed reference 0
Like P3.2 Assignment of control signal terminal
Switch between the setpoint sources AI1 and AI2 set at
P6.2 and P6.18
P3.27 1414 — Activate second parameter set (2PS) 0
Like P3.2 Assignment of control signal terminal
The values set at the parameter group P14 are activated
P3.28 1415 — Fieldbus, remote input 0
Like P3.2 Assignment of control signal terminal
The assigned digital input is written directly to the general
status word (ID 2102, bit 11)
P3.29 1416 — Counter reference value 1 0
0–65,535 Trigger value for P5.1–P5.3 = 20
P3.30 1417 — Counter reference value 2 0
0–65,535 Trigger value for P5.1–P5.3 = 21
P3.31 1418 — DI1 logic (control signal terminal 8) 0
The logic activates the response of the control signal
terminal (see figure on Page 71)
N/O contact (failsafe) N/C contact
0 N/O contact
1 N/C contact
P3.32 1419 — DI2 logic (control signal terminal 9) 0
Like P3.31 Function
