Effective 10/02
Page 4-9
For more information visit: www.cutler-hammer.eaton.com
Page 4-9
IL17562BH04
Selected
Value
Line
No.
8
9
10
11
12
Display
INSQ XXX
INSQ TRN
or
INSQ ST
LAT XXX
ZSW ON
or
ZSW OFF
ABK XXXX
Help Message
INCOMPLETE SEQUENCE REPORT
BACK TIME IN SECONDS ON
DISCRETE INPUT 2
INCOMPLETE SEQUENCE START
TIMER EVENT
INSQ TRN – START TO RUN TRANSITION
INSQ ST – STOP TO START TRANSITION
LONG ACCELERATION TIME
IN SECONDS
ZERO SPEED SWITCH ON DISCRETE
INPUT 1 ON OR OFF
ANTI-BACKSPIN DELAY TIME
IN SECONDS
Setting
Range/ Value
Selection
1-240 sec., OFF (1
sec. increments)
Note: Choosing a
time value here
(not OFF) also
locks P7L1 to INC
SEQ and no other
choices are
available there.
Also, if this is set
to OFF, later
setting of P7L1 to
INC SEQ will force
a setting of 1
second here.
Toggles between
INSQ TRN and
INSQ ST
1-1200 sec., OFF
(1 sec. increments)
Danger - set to
OFF unless
absolutely needed.
If used, connect
zero-speed switch
- see P5L11 and
P6L1.
Toggles between
ZSW ON and
ZSW OFF.
Note: Choosing
ZSW ON here
also locks P6L1 to
ZERO SW and no
other choices are
available there.
Also, setting P6L1
to ZERO SW will
force ZSW ON
here.
1-3600 seconds,
OFF (1 second
increments)
Value
as
shipped
1
INSQ ST
OFF
ZSW
OFF
OFF
Section
Reference
5.5.8
5.5.9
5.5.10
5.5.1.1
5.5.1.2
