UPS STARTUP
EATON Powerware
®
9170
+
UPS (3–18 kVA) User’s Guide S 164201393 Rev C www.powerware.com
75
18. The UPS front panel display automatically turns on whenever input
power is present and at least one power module is installed. Set up
the initial operating parameters through the front panel display (see
“Initial Startup Parameters” on page 75).
NOTE The unit has no physical On/Off switch. Access the UPS On/Off function through the
front panel display.
NOTE If the UPS has been manually set to operate in Bypass or Battery mode, change the
System Control Mode Preference (menu 4 1) to Auto to return to normal Auto mode operation.
19. If applicable, test proper operation of optional external control
signals and computer communication before connecting the load.
(See “DB-9 Communication Port” on page 94 for details.)
20. If there are receptacles on the UPS rear panel, plug the equipment
to be protected into the UPS output receptacles.
NOTE DO NOT protect laser printers with the UPS because of the exceptionally high power
requirements of the heating elements.
21. Turn on the equipment that is connected t o t he UPS.
22. If there is an external bypass switch, turn it t o UPS. Otherwise,
close the load distribution circuit breaker(s).
Initial Startup Parameters
The first time the UPS is turned on, you must set or verify certain
operating parameters before placing the UPS into operation. To set
these initial configuration parameters:
1. Enter the correct user security password: 0377. Move left and right
by pressing the buttons below the <- and -> on the display. To
change the value of the selected digit, press the
and
buttons.
When the password shows 0377, press the
button.
ENTER PASSWORD
Password - 0000
<- -> ESC
