6 Technical Data
6.4 Cable cross-sections
160 DC1…20… and DC1…OE1 Variable Frequency Drives 02/20 MN040059EN www.eaton.com
Mains voltage 230 V
Supply voltage (50/60 Hz) U
LN
200 (-10 %) - 240 (+10 %) V
U
e
230 V AC, three-phase / U
2
230 V AC, three-phase
DC1-322D3… FS1 8 8 3.4 1.5 14 2.3 1.5 14
DC1-324D3… FS1 8 8 5.6 1.5 14 4.3 1.5 14
DC1-327D0NN… FS1 8 8 9.5 1.5 14 7 1.5 14
DC1-327D0NB… FS2 8 8 8.9 1.5 14 7 1.5 14
DC1-327D0FB…
FS2 8 8 8.9 1.5 14 7 1.5 14
DC1-32011… FS2 8 8 12.1 2.5 12 10.5 1.5 14
DC1-32018… FS3 8 8 20.9 6 10 18 2.5 10
DC1-32024… FS3 8 8 26.4 10 8 24 4 10
DC1-32030… FS4 16 5 33.3 16 8 30 6 8
DC1-32046… FS4 16 5 50.1 16 6 46 10 6
Mains voltage 400 V
Supply voltage (50/60 Hz) U
LN
380 (-10 %) - 480 (+10 %) V
U
e
400 V AC, three-phase / U
2
400 V AC, three-phase
DC1-342D2… FS1 8 8 3.5 1.5 14 2.2 1.5 14
DC1-344D1NN… FS1 8 8 5.6 1.5 14 4.1 1.5 14
DC1-344D1FN… FS1 8 8 5.6 1.5 14 4.1 1.5 14
DC1-344D1NB… FS2 8 8 5.6 1.5 14 4.1 1.5 14
DC1-344D1FB… FS2 8 8 5.6 1.5 14 4.1 1.5 14
DC1-345D8… FS2 8 8 7.5 1.5 14 5.8 1.5 14
DC1-349D5… FS2 8 8 11.5 2.5 12 9.5 1.5 14
DC1-34014… FS3 8 8 17.2 4 10 14 1.5 14
DC1-34018…
FS3 8 8 21.2 4 10 18 2.5 10
DC1-34024…
FS3 8 8 27.5 8 8 24 4 10
DC1-34030…
FS4 16 5 34.2 16 8 30 6 8
DC1-34039… FS4 16 5 44.1 16 6 39 10 8
DC1-34046… FS4 16 5 51.9 16 5 46 10 6
1) AWG = American wire gauge
kcmil = Thousands of circular mils (1 kcmil = 0.5067 mm²)
Device Type
Size Maximum
terminal capacity
Input current
I
LN
Cross-sectional area/
gauge that should be
used for the power
supply (L1/L, L2/N, L3, PE)
Output
current (rated
operational
current) I
e
Cross-sectional area/
gauge that should be
used for the motor
connection (U, V, W, PE)
mm
2
AWG/
kcmil
1)
A mm
2
AWG/
kcmil
1)
A mm
2
AWG/
kcmil
1)
