Mounting the new battery module
Carry out the above instructions in reverse order.
w To ensure safety and high performance, use only batteries supplied by EATON.
w Take care to firmly press together the two parts of the connector during remounting.
E. Pull the plastic tab to remove the battery
block and replace it.
D. Remove the metal protection cover in front of
the battery (two screws).
5. Maintenance
86-81710-00EN A03 - Page 23
