PTO Configurations
Heavy-Duty Manual Transmission - FR Series
Note: (LL) Lower Left, (UR) Upper Right
Model 8-Bolt Gear Info. 6-Bolt Gear Info. Thru-
Sha
ft
Int.
Spline
Info.
Ext. Aux.
Counter-
shaft PTO
Ext.
Spline
Info.
% of
Engine
Speed
Transmission
Torque Limit for
PTO use (lb-ft)
FR-11210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 65
500
6
FR-12210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 65
FR-13210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 65
FR-14210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 65
FR-15210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 65
FRW-15210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 65
FRM-15210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 87
FR-9210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 65
FRO-11210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 87
FRO-11210C Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 84
FRO-12210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 87
FRO-12210C Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 84
FRO-13210B Yes
47T 6.0P,
20DEG PA
Yes
9
45T 6.0P,
20
DEG PA
LL & UR
32T 0.5P,
30DEG PA
N/A N/A 87
Note: (6) - Intermittent torque of up to 750 lb-ft at the countershaft is permitted for 5 minutes of each 15 minute PTO duty cycle.
