57
Inertia Brake
Inertia Brake Right-Hand Mounting Installation Instructions -
Medium-Duty
This kit provides hardware and instructions for moving a Medium-Duty inertia brake from the left side to the right side of the
transmission. This kit is only for use with transmissions already fitted with inertia brakes that can be mounted in either location.
This is easily determined by the existence of 2 speed sensor adapter ports on the inertia brake casting. If the transmission does
not already have this style inertia brake, a different kit containing the correct inertia brake needs to be ordered. The correct inertia
brake is required to keep the speed sensor pointing upwards to prevent oil leakage.
Items in kit:
• (3) PTO Cover Gaskets (4305309)
• (1) Jumper Harness (4306106)
• (1) Harness Strap Bracket (4305794)
• (4) Ty-rap (5559348)
• (1) Thread Sealant (71205)
• (1) Thread Adhesive (71232)
• (1) Wire Harness Terminal Lubricant (Nyogel) (5564527)
Drain Oil from Transmission
Remove drain plug and drain oil out of transmission.
Oil may be hot.
T
-ra
Hose
Harness
To Next Page
