Inertia Brake
Generation 3 - Inertia Brake Relocation Instructions - Heavy-Duty
(8 to 6-Bolt PTO Opening)
Oil may be hot.
Note: Drain the lubricant
from the transmission. Drain the lubricant from the Inertia Brake. On older product the Inertia Brake will
still remain full of lubricant (no drain plug).
Removal
1. Disconnect the Transmission Harness from the Inertia Brake and remove tie straps restraining this harness branch.
Note: Use care not
to damage the harness. Protect the connector end from dirt contamination.
2. Disconnect the lubricant supply line from the Inertia Brake.
The Inertia Brake is heavy. Be prepared to handle the weight of the Inertia Brake when the mounting bolts are removed. Protect
the connector body from impact and contamination.
3. Remove the six (6) mounting bolts
from the Inertia Brake.
4. Remove the Inertia Brake and gasket from
the adapter plate.
5. Remove the eight (8) mounting bolts from the adapter plate.
6. Remove and discard the adapter plate and ga
sket from the transmission.
7. Remove the six (6) mounting bolts from the 6-bolt PTO cover.
8. Remove and discard the 6-bolt PTO cover and gasket
from the transmission.
Note: Clean and remove all old gasket material from the
mating surfaces of the Inertia Brake and transmission PTO openings.
Locate the harness push-in anchor point for reference during re-installation to 6-bolt opening.
