Eaton VICKERS SystemStak - Page 8

Model E F G
DGMC-3-AB-*W-4* –– 164 (6.5)
DGMC-3-BA-*W-*-4* – 164 (6.5) –
DGMC2-3-AB-*W-BA-*W-4* 234 (9.2) ––
A
P
B
T
E max.
Line B adjustmentLine A adjustment
16,75 (0.66)
8 (0.13) max.
G max.
F max.
16,75 (0.66)
10 (0.4) max.
8
Installation Dimensions in mm (inches)
