START-S1XL
Operating Guide
-2-
Foreword
This manual provides all the specic information
youneedtofamiliarizeyourselfwithandcorrectly
operateyourunit.Readitverycarefullywhenyou
purchase the instrument and consult it whenever
youhavedoubtsregardinguseandbeforeperfor-
ming any maintenance operations.
Environmental protection
measures
Information regarding the environment
for customers within the European
Union. European Directive EC 2002/96
requires that units bearing this symbol
on the unit and/or on the packaging be
disposedofseparatelyfromundifferenti-
ated urban wastes.
The symbol indicates that the product must not be
disposed of with the normal household wastes.
Theownerisresponsiblefordisposingofthisprod-
uct and other electrical and electronic equipment
throughspecicwastecollectionfacilitiesindicated
by the government or local public agencies. Correct
disposal and recycling help prevent any potentially
negative impact on the environment and human
health. To receive more detailed information re-
gardingdisposalof yourunit,werecommendthat
you contact the competent public agencies, the
waste collection service or the shop Where you
purchased the product.
Piccol Small dictionary
FCA o FCO necorsaapre
FCC necorsachiude
START comando movimento cancello
PEDESTRIAN comando apertura parziale
Vac (alternate current) corrente alternata
Vdc (direct current) corrente continua
NC normalmente chiuso
NA o NO normalmente aperto
Contatto pulito isolato dalle tensioni di alimentazione
Safety precautions
Usingtheunitimproperlyandperformingrepairsor
modicationspersonallywillvoidthewarranty.
Nologo declines any responsibility for damages
due to inappropriate use of the product and due
to any use other than the use the product was de-
signed for. Nologo declines any responsibility for
consequentialdamagesexceptcivilliabilityforthe
products.
Index
Technical caracteristics
Power supply Vac 230
Contactoftherelay up to 1Hp motors
Operating temperature
0
C min/Max
-20°C÷+60°C EN 600068-2-
1 EN 600068-2-2
Protecion level IP 45
Dimensions mm b67 x h110 x p32
Cap Pag
1
Installation and scheme of the control unit
3
2
Functions and adjustments
4
Remote control:
10
3
Cancellationofthememory
3.1
Activationofthecodes
3.2
Code memorisation
11
4
Scheme and Symbol
12
5
Programming
5.1
Working time program
5.2
CancelationoftheWorkingtime
13
5.3
Fixedlightorashing
6
Note
7
Connection of the BUS DATA SYSTEM
14
7.1
ExampleoftheinstallationofBUSL2
8
Declaration of CE conformity
15
