START-S1XLver2_240517_VXX02 _ES www.ebtechnology.it www.nologo.info
Central monofase para motores 230V para persianas, cortinas y cierres enrollables.
Receptor incorporado
Versión normal - Versión hombre presente
Gestión anemometro ó apertura/cierre centralizado
START-S1XL v2
Instrucciones y advertencias
100%
ITALY
Instrucciones y advertencias
-16-
-17-
-1-
-2-
-3-
-4-
-5-
Contacto limpio
Entrada 230 Vac
Entrada 230 Vac
mpara
Com MOT / LAMP
MOT ABRE
-6-
MOT CIERRA
M
AB
CI
COM
-7-
-8-
-9-
-10-
-11-
+ Antena
Comùn / - Antena
Salida 12 Vac
Salida 12 Vac / + 12Vdc
- 12Vdc, Comùn
-12-
CIERRA / STOP
-13-
-14-
FOTO / ANEMOMETRO
ABRE / START
-15-
BUS-DATOS
Alim OUTAlim
TX
RX
N.C.
N.A. N.A.
DIP 3B
ON
DIP 3B
OFF
Fotocélula activa
sólo en cierre
2002/95/EC
Programar JUMPER J1 AC/DC
como la foto de abajo
JUMPER J1
AC: 12 Vac
borne 9-10
DC: 12 Vdc
borne 10-11
Alimentación de los acessorios
JUMPER J1
Para pasar de lámpara ja a destellante simplemente mantener pulsado
el botón P durante la maniobra de cierre hasta que el Led no parpadee.
Contacto limpio
Para una correcta instalación
de la lampara leer parrafo 1.2
