(22)
2. Output Signal
1. Input signal
MP Start
BP Start
Reset
Emergency Stop
Switch [ OPTION ]
Remote / Local
Casing Temp. (TRIP)
MP Run
BP Run
MP Stop
BP Stop
6
+
DC12V
(-)
2
(+)
1
1 kOHM
(+)
Open
collector
Dry
contact
Control
Connector
3
4
8
9
50
+
27
+
26
Inductive
load
12
14
+
Resistance
load
11
+
DC50V
Max. 50mA
DC50V
Max. 50mA
5
(+)
(+)
(+)
[ NOTE ]
1. Insert a diode (100V / 1A class) when
connecting inductive load by output signal.
2. Do not connect wiring to opened pins.
It may cause malfunction.
DC50V
Max. 50mA
DC50V
Max. 50mA
Figure 4.6 Control Signal Wiring
EBARA Corporation
