- 30 -
STEP.9
Remove Nut(6) from Shaft(5).
STEP.10
Remove Pump Bushing(4) from Shaft(5).
STEP.11
Remove Key(11) from Shaft(5).
STEP.12
Remove Stud Bolt(8) from Motor Bushing(2).
STEP.13
Remove Set Screw(3) from Motor Bushing(2).
STEP.14
Heat the Motor Bushing (2) with a burner and
pull out with a pulley removing tool.
