EBR 1190 SX - Page 23

To Next Page

To Previous Page

Turn Signal Headlight Clutch Lever

Ignition

switch

Fuel Filler

Battery

(under seat)

Tail/stoplight

Passenger

Footpegs

Gear Shifter Sidestand

Figure 1. 1190 SX Left Side View.
