EBR 1190 SX - Tires; Bulb Chart; Dimensions

Tires
Tire
Type
Solo Riding
Loaded GVWR
PSI
kPa
PSI
kPa
Front
Pirelli Diablo Rosso Corsa
36
248
36
248
Rear
Pirelli Diablo Rosso Corsa
34
234
34
234
Table 8.
Bulb Chart
Bulbs
Bulbs Required
WATTS
AMPS
Part Number
Headlamps
LED Assembly; replace entire assembly upon failure.
Tail Stop Lamp
LED Assembly; replace entire assembly upon failure.
License Plate Lamp
LED Assembly; replace entire assembly upon failure.
Front Turn Lamps
2
10
0.74
Y0042.1B6
Rear Turn Lamps
2
10
0.74
Y0042.1B6
Instrument Cluster
LED Assembly; replace entire assembly upon failure.
Table 9.
Dimensions
Item (Without Rider)
In.
MM
Overall Length
80.3
2040
Overall Width (without mirrors)
29RX/ 31.9 SX
737/810
Overall Height (without mirrors)
43.7 RX/42.8 SX
1110/1087
Wheel Base (unladen)
55.6
1412
Seat Height (unladen)
32.5
826
Trail at Ride Height
3.8
96
Rake at Ride Height
22.4 degrees
22.4 degrees
Table 10.
