EBR 1190 SX - Specifications; Engine Specifications

SPECIFICATIONS
2014 EBR 1190 RX/SX MODELS
ENGINE
Item
Specification
Cylinders
2
Type
72 Degree V-Twin, Liquid Cooled, four-stroke
Bore
4.173 in.
106.00 mm
Stroke
2.658 in.
67.50 mm
Displacement
72.6 cu. in.
1191 cc
Compression Ratio
13.4:1
Valve Train
DOHC, four valves per cylinder
Fuel Delivery
Electronic Fuel Injection
Lubrication
Dry sump, reservoir integrated in the engine
Battery
Li-ion, 13.2 volt, 7 amp/hr, 315 cold cranking amps
Spark Plugs
NGK CR9EKB
Size
10 mm
Gap
.032 in.
0.81 mm
Torque
7 – 9 ft-lbs
10- 12 Nm
Table 2.
NOTE: Specifications in this document may not match those of official certification in some markets due to timing of this documents
publication and printing, variance in testing methods, and/or vehicle differences. Customers seeking officially recognized regulatory
specifications for their vehicle should refer to certification documents and/or contact their respective dealer or distributor.
