Figure 50. Right side drain plug.
NOTE
Refer to Table 21 to determine if the oil filter cartridge needs
to be replaced.
Figure 31. Oil Filter Cover.
6. If replacing the oil filter cartridge, perform the
following:
A. Remove the two screws to detach the oil
filter cover. See figure 31.
B. Clean the cover and inside the oil filter
recess in the crankcase. Remove any debris.
88
