The BOLTMARK
®
II‑series PrinTers
Basic OPeraTing insTrucTiOns
7 2018/02/27#2.0EN
Printer inStallation
The printer should be installed for the rst me by the distributor’s authorized serviceman.
A trained user can reinstall/move the printer to another workplace provided that the printer:
• is lled with ink,
• has previously been prepared for transporng in compliance with the instrucons given
in The BOLTMARK
®
II‑series Printers User Manual or
has been supplied without iModule
®
, and a new iModule
®
unit (or the one used in that print-
er before) has been delivered separately.
Recommended modes of installaon
• installing on a CIJ printer stand,
• installing on a hanger,
• installing on a rm table.
Place the printer in a convenient place to ensure easy access to:
• operator panel,
• accessories connector plate, including main power switch POWER, which is a safety cut-o
switch,
• the consumables chamber
Discharge vapors to the outside of the building.
Secure the printer and other elements of the prinng system against movement.
Connect the protecve pin of the printer to a grounded element of the industrial plant.
Install the printhead in a place that:
• ensures convenient access to objects to be labeled,
• is free from shocks and vibraon,
• makes contact of the head cable with another object impossible.
The printhead can print in any posion.
The minimum head cable bend radius is:
• 75 mm for stac operaon,
• 150 mm for dynamic operaon.
