10.3. DATA TRANSMISSION
During data transmission a green diode OK indicates data transmitting.
Description
LED Diodes
OK (green)
ERROR
(red)
GPRS Transmission
SMS Transmission
10.4. RECEIVING OF DTMF DATA
Diodes marked as DTMF and STATUS indicate actual condition during receiving data
from a control pane.
LED Diode
Signalling
STATUS
DTMF
(HandShake) (KissOff)
6 digits of phone 16 digits ContactID
DTMF ERROR OK STATUS
DTMF ERROR OK STATUS
DTMF ERROR OK STATUS
