2. FUNCTIONAL AND TECHNICAL PARAMETERS
Transmission channels
GPRS, SMS, PSTN*
*transparent, PSTN dialer required in a CP
Backup server
YES (GPRS, SMS)
User notifications
SMS (5 phone numbers)
Communication watchdog
YES
Inputs
5 (NO / NC / EOL-NO / EOL-NC / DEOL-NO /
DEOL-NC)
Partitions
2
Simulated PSTN Line
YES
Protocols supported on the phone input
SIA, ContactID
Control panel dialer bypass
YES
Voice gateway functions
-
Outputs
2 (OC, max. load 100mA)
Output functions
- unavailable GSM signal
- GSM jamming (only for BGS2-W module)
- from server or through SMS
- incoming CLIP
- in reaction on events and inputs
RC Receiver: 434 MHz
NO (optional)
Max.number supported keyfobs
-
Power output +12V
-
Serial interface
RS232 / RS485 (lines: RxD, TxD, RTS, CTS)
transmission speed up to 115200bps
Alarm events buffer size
-
Quantity of system events stored in
history
min. 5000
Event's timestamps
-
GPRS/SMS transmission security
AES encryption
Status LEDs
(functions)
4 LEDs (GSM signal level, device state, DTMF
communication)
Configuration
Remote: GPRS, SMS, CSD
Local: PC through RS232 (required cable: GD-
PROG or SP-PROG)
Remote firmware update
YES
Remote access to the control panels
-
Phone line protection circuit
YES
Dual SIM
only in LX20B-5D model
Multiantenna steering output
NO (optional)
Supported modems
model LX20B-50: Cinterion BGS2-W (Quad-Band
GSM: 850, 900, 1800, 1900 MHz);
model LX20B-5D: Cinterion BGS2-W (Quad-Band
GSM: 850, 900, 1800, 1900 MHz);
model LX20B-60: Cinterion EHS6 (Quad band
850/900/1800/1900MHz);
model LX20B-70: Cinterion EHS5-E (Dual-Band
UMTS: 900, 2100 MHz; GSM: 900, 1800 MHz);
model LX20B-80: Cinterion EHS5-US (Dual-Band
UMTS: 850, 1900 MHz; GSM: 850, 1900 MHz);
Ethernet
−
