LX20B – Manual Page 8 / 67
Power supply
parameters
- PCB
Voltage supply
13.8VDC (acceptable: 12-14VDC)
Power consumption
DC (AKU)
(average / max)
73mA/155mA@13.8VDC*
* Measured with full charged battery, modem
BGS2-W Cinterion
95mA/125mA@13.8VDC*
* Measured with full charged battery, modem
EHS5-E Cinterion
100mA/125mA@13,8VDC*
* Measured with full charged battery, modem
EHS6 Cinterion
Power consumption
AC (AC)
(average / max)
-
Power supply
parameters
- PCB in EBS
plastic casing
Voltage supply
230V
AC
(acceptable: 190-250V
AC
)
Power consumption
(average / max)
3W/10W@230V
AC
(recommended transformer
20W)
Charging module functions
-
Backup battery connection
-
Battery charging current
-
Threshold of signaling low AC voltage
(at secondary / at primary)
-
Threshold of signaling low battery
voltage
-
Cut-off battery voltage level
-
Dimension
PCB: 102 x 73 x 20mm
Working temperature
-10ºC … +55ºC
Working humidity
5% … 93%
Standards
CE
