EBS LX20G - Page 64

LX20G_Manual_en_v2.1
Page 64 /
69
UN=un
APN user name. Parameter should be obtained from mobile
network operator. If APN user name contain space sign put
it with “” e.g. “my user name”.
PW=pw
APN password. Parameter should be obtained from mobile
network operator. If APN password contain space sign put it
with “” e.g. “my password”.
SERVER=server
Server address; it can be in form of IP or domain name
address.
PORT=port
Server port number.
DNS1=dns1
Specifies primary DNS server address (only needed when
domain name address is used as SERVER address)
DNS2=dns2
Specifies secondary DNS server address (only needed when
domain name address is used as SERVER address)
SMS=phone number
Server phone number. When there is GPRS failure, SMS
with events will be sent to this number.
SMSPERIOD=time
Defines in minutes time between SMS test messages
sending to the server.
OLD
Switch device operating in encoded protocol mode into
operation in old PX device emulation mode.
RLIMIT
Removes automatic temporary locks on all inputs
RLIMIT=inputs_mask
Removes selected automatic temporary locks. Parameter is
decimal number made from 9-bit word: A9 … A2, A1, where
A1 means TAMPER, A2 INPUT 1 and A9 INPUT8.
EXAMPLE:
RLIMIT=7 removes locks on inputs: TAMPER, IN1, IN2
RLIMIT=1 remove lock on input TAMPER
DT=YY/MM/DD,hh:mm:ss
Sets date and time in the transmitter; must be putted in a
specific format (see the table on the left)
FLUSH=x
Flushes events buffer, where x is:
 0 – primary dialer’s events buffer
 1 – secondary dialer’s events buffer
 2 – system events history
All the dialer’s events are being saved always in the buffer
0, but in the buffer 1 only when the option “Both receiving
stations must acknowledge events” has been chosen.
Note: DESC, CMD, GETSTATUS, GETPARAM, GETCFG commands require separate
SMS, so one command with only one SMS.
