EBS LX2NB - 2 Functional and Technical Parameters

LX2NB Manual v.1.9 Page 7 / 60
2. FUNCTIONAL AND TECHNICAL PARAMETERS
Inputs:
(programmable)
4 signal inputs (NO, NC, EOL-NO, EOL-NC, DEOL-NO,
DEOL-NC),
1 DTMF
Outputs:
(programmable)
1
Operation modes:
 GPRS transmission only
 SMS transmission only
 GPRS and SMS transmission
Messages:
Sending of text messages for defined mobile phones
Configuration:
Remote – via GPRS link
Remote- SMS
Remote – CSD
Locally –from PC with the use of software and GD-PROG
cable with RS-232 link
Security:
SMS/GPRS transmission – AES encoding
Loading of OUT1 output
50 mA
Working temperature
-10ºC ~ +55 ºC
Operating humidity
5% - 93%
In dependence from user's decision "Transmitter LX” can be delivered in different
versions. Therefore also the parameters as type of the power supply voltage,
current consumption as well as the dimensions were introduced for following options
separately:
Option 1 – Transmitter LX2NB + power supply LX-ZAS in metal/plastic box
Option 2 – PCB of transmitter LX2NB
Option 1
Option 2
Voltage
typ. 230 V AC
(190 – 250 V AC)
50 – 60 Hz
typ. 13.8 V DC
(12 – 14 V DC)
Current/Power
consumption
(average/max)
3 W / 20 W
@230 V AC
60 mA /340 mA
@13.8 V DC
75 mA / 340 mA
@13.8 VDC (with radio receiver
433.92MHz)
Dimensions
255 x 255 x 90 mm
(metal/plastic box)
102 x 73 x 35 mm
