ECCI TRACKSTAR 6000 - Pedal Unit Components; Assembled Pedal Unit - Side View

TRACKSTAR
GROUNDING CABLE
POT CARTRIDGE
PEDAL ARMS
PEDAL PADS
Figure 8 - PEDAL UNIT COMPONENTS
BASE ASSEMBLY
PEDAL FRAME ASSEMBLY
DIAGONAL STRUTS
BASE ASSEMBLY
Figure 9 - ASSEMBLED PEDAL UNIT - SIDE VIEW
PIVOT A
PEDAL TENSION
ADJUSTERS
ANGLE ADJUSTMENT
PIVOT
SLOT
PIVOT
PIVOT BOLTS, NUTS
HEEL REST
HEEL REST
ADJUSTMENT
BRACKET
PEDAL FRAME
PIVOT D
DIAGONAL
STRUTS
PMB CAM PLATE
MOUNTING BOLT
CONNECT GROUND CABLE TO COMPUTER CHASSIS SCREW -OR-
THE COVER SCREW OF A GROUNDED ELECTRICAL OUTLET -OR-
METALLIC WATER SUPPLY PIPE -OR- OTHER SUITABLE GROUND
GROUND CABLE
& WASHERS
C
B
