ECCI TRACKSTAR 6000 - Steering Potentiometer Wire Connections

TRACKSTAR
CLUTCH PEDAL POT
DIRECTION
OF POT
ROTATION
G
I
I
H
BRAKE PEDAL POT
(NON-PMB UNIT)
D
F
E
TIE DOWN
POINT FOR
CABLE TIE
I
POT TERMINALS
WIRE COLORS
POT TERMINALS
WIRE COLORS
I
I
Figure 19 - STEERING POTENTIOMETER WIRE CONNECTIONS
OUTER TERMINALS OF ALL
POTS ARE BRIDGED WITH A
JUMPER LEAD. THE LEADS
ATTACHED TO THE JUMPER
ARE ALWAYS TO BE
CONNECTED TO THE
OUTSIDE POT TERMINALS
BLUE WHITE RED
JUMPER LEAD
BLUE
ORANGE
PINK
WHITE
BLACK
RED
NOTE:
DIRECTION
OF POT
ROTATION
