ECCI TRACKSTAR 6000 - Steering Unit Layout; USB HD-ULTRA R6000.2 Logic Board Layout

TRACKSTAR
Figure 6 - STEERING UNIT LAYOUT
Figure 7 - USB HD-ULTRA R6000.2 LOGIC BOARD LAYOUT
POTENTIOMETER
HEADER
USB TERMINAL
HEADER
SYSTEM LOGIC
CHIPS
DIGITAL BUTTON
HEADER
JUMPER J-1
6 - BUTTON MODE
2 - BUTTON MODE
MOUNTING
SCREWS
STEERING POTENTIOMETER
USB CIRCUIT BOARD
ACCESSORY
EXPANSION
PORT CABLE
(OPTIONAL)
PEDAL UNIT
CABLE
ELECTRONICS PAN
FLDS FLUID
DAMPER
MONOPOINT II
CAM SYSTEM
USB SYSTEM
CABLE
