1 Specifications
Power Supply 13.2V DC (11-16V)
Current Drain 3A
Dimensions (whole unit) (W x H x D) 7" x 4" x 6-1/2" (180 x 100 x 165mm)
Weight (whole unit) 5.5lbs (2.5kg)
Dimensions (PND only) (W x H x D) 5" x 3" x 1" (130 x 82.5 x 24.5mm)
Weight (PND only) 0.4lbs (0.2kg)
Operating temperature range (whole unit) -4°F to 149°F (-20°C to +65°C )
Operating temperature range (PND only) 14°F to 131°F (-10°C to +55°C )
Storage temperature range (Audio only) -20°F to +185°F (-40°C to +85°C )
PND safe storage temperature range* -4°F to 140°F (-20°C to +60°C)
Suitable load impedance 4Ω
*:There is the possibility that the PND safe storage temperature limit could be exceeded. Please do not leave
the PND in a vehicle for extended periods of time, as doing so could damage it.
DISPLAY 4.3" WQVGA
Resolution 480 x 272 pixels
Frequency Range AM 530~1710kHz (10kHz step) (For North America)
AM 530 ~ 1710kHz (10kHz step) (For Latin America)
AM 522 ~ 1629kHz (9kHz step) (For Asia)
AM 522~1710kHz (9kHz step) (For Australia)
FM 87.75~107.9MHz (200kHz step) (For North America)
FM 87.75 ~ 107.9MHz (100kHz step) (For Latin America)
FM 87.5 ~ 108MHz (50kHz step) (For Asia)
FM 87. 5~108.0MHz (100kHz step) (For Australia)
Usable Sensitivity AM 27dB (1kHz)
FM 15dBf
50dB Quieting Sensitivity FM 24dBf
Stereo Separation FM 40dB (1kHz)
Frequency Response 20Hz~20,000Hz, ±3dB
Wow & Flutter Below measurable limits
Channel Separation 65dB
S/N Ratio (A-weighted)
CD 75dB
DVD 70dB
Dynamic Range 95dB
Total Harmonic Distortion 0.008%
USB Interface 1.1
Frequency Response 20Hz~20,000Hz, ±3dB
S/N Ratio (A-weighted) 75dB
General
Display
Radio tuner
CD/DVD
USB memory
