GPS - INSTALLATION
AMM-34-50-11-041-801-D
1. General
A.
This task gives the procedure to install the Global Positioning System/Wide Area
Augmentation System (GPS/WAAS) sensors.
B. There are two GPS/WAAS sensors installed in the aircraft. Installation steps are the
same for the light and right sides, unless specified.
2.
Job Set-Up
SUBTASK AMM-34-50-11-041-D-921-001
A.
Make sure the aircraft is in the same configuration it was when the removal task was
completed. Refer to AMM-34-50-11-001-801 – GPS - Removal.
3.
Procedure
SUBTASK AMM-34-50-11-041-D-411-001
(Refer to Fig. 401.)
A.
Put the GPS/WAAS sensor (4) on the mounting bracket (5) and align the bolt holes.
(1) Make sure the electrical connectors are facing forward.
(2) For the left side sensor, make sure the GPS/WAAS sensor (4) mounting flange is
toward the outboard side of the aircraft and against the mounting bracket (5) .
(3) For the right side sensor, make sure the GPS/WAAS sensor (4) mounting flange is
toward the inboard side on the aircraft and away from the mounting bracket (5) .
B. Attach the GPS/WAAS sensor (4) to the mounting bracket (5) .
(1) For the left side GPS/WAAS sensor (4) , attach the sensor (4) to the mounting
bracket (5) with the four bolts (1) .
(2) For the right side GPS/WAAS sensor (4) , attach the sensor (4) to the mounting
bracket (5) with the four bolts (1) and spacers (6) .
C. Torque the bolts (1) to between 30-40 lbf.in (3.4-4.5 Nm).
D. Bond the GPS/WAAS sensor (4) to the aircraft. Refer to AMM-20-03-00-051-801 –
Electrical Bonding - Maintenance Practices.
(1) Make sure the resistance is not more than 2.5 millohms.
E. Remove the protective caps from the electrical connector (2) and Coax Threaded Neil-
Concelman (TNC) connector (3) .
F. Connect the electrical connector (2) and Coax TNC connector (3) .
G. Apply power to the aircraft. Refer to AMM-24-40-00-051-801 – External Power -
Maintenance Practices.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: ALL POST MB 500-31-007 OR MB
500-31-008
34-50-11
CONFIG D
Page 401-Inst
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
