Page #49 background image
PITOT/AOA PROBE - INSTALLATION
AMM-34-10-14-041-C-801
1. General
A.
This task gives the procedures to install the Pitot/Angle of Attack (AOA) probes.
2.
Job Set-Up
SUBTASK AMM-34-10-10-041-C-921-001
(Refer to Fig. 401, Sheet 1.)
A.
Make sure aircraft is in the same configuration as it was when the removal task was
completed. Refer to AMM-34-10-10-001-C-801 – Pitot/AOA Probes - Removal.
B. If the Pitot/AOA probe is new, check to see if a packing (support) block (1) is supplied
with the unit.
NOTE: New assemblies may be shipped from the manufacturer with a packing block (1)
in order to protect the device during shipping, handling and installation.
(1) It is strongly recommended that new Pitot/AOA probe(s) should be mounted to the
aircraft with the packing block (1) still in place in order to prevent pinching and kinking
of the main plumbing line (2) and connection (3) during the installation process. It is
also recommended that a Pitot cover be used on the Pitot/AOA probe as practical
during and after installation in order to provide increased protection against foreign
object damage (FOD).
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: ALL, POST MB 500-34-027 AND MB
500-34-028
34-10-10
CONFIG C
Page 401-Inst
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
