Eclipse EA500 - Stormscope - Description and Operation; General; Description; Operation

STORMSCOPE - DESCRIPTION AND OPERATION
AMM-34-40-50-081-A-801
1. Introduction
A.
The Lightning Detection System (LDS) on the aircraft is referred to by it’s trademark
name Stormscope®. Stormscope is a passive thunderstorm detection sensor. The sensor
maps electrical discharge activity 360 degrees around the aircraft to a distance of 200
nautical miles for display on the GPS 400W display. Refer to Fig. 1.
2.
Description
SUBTASK AMM-34-40-50-081-871-001
A.
The Stormscope system detects electrical discharges from thunderstorms within a 200
nm (370 kM) radius of the aircraft for display on the pilot (left side) Garmin GPS 400W
also referred to as GPS 1. Stormscope has a passive sensor that receives electronic
signals through a stormscope antenna. The processor receives electrical discharge
information from the antenna, processes it to determine range and azimuth and
processes the heading input.
3.
Operation
SUBTASK AMM-34-40-50-081-871-002
A.
Stormscope provides the following functions:
• Two modes of weather display are available, Strike mode and Cell mode.
• It works on the ground and in air giving the pilot information before take-off and in
flight.
• It displays range and azimuth to lightning strikes/lightning cells.
• The antenna detects electrical and magnetic signatures of lightning strikes.
• Operates passively requiring no transmitter.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001 - 0008, 0010 - 0050, 0052, 0054 -
0267 PRE SB 500-31-024
34-40-50
CONFIG A
Page 1
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
