GPS 2 ANTENNA SPLITTER - REMOVAL
AMM-34-50-14-001-801
1. General
A.
This task gives procedures to remove the GPS 2 Antenna Splitter.
B. There is one GPS 2 Antenna Splitter installed on the aircraft under 231 NZ - Floor Panel,
Baggage Compartment.
2.
Job Set-Up
SUBTASK AMM-34-50-14-001-921-001
A.
Make aircraft safe for maintenance. Refer to AMM-20-00-01-051-801 – Make Safe For
Maintenance.
B. Make sure all power is removed from the aircraft.
C. Remove 231 NZ - Floor Panel, Baggage Compartment. Refer to AMM-06-50-00-051-801
– Aircraft Access Panels for location and removal instructions.
3.
Procedure
SUBTASK AMM-34-50-14-001-C-011-001
(Refer to Fig. 401.)
A.
Disconnect the three coaxial connectors (3) from the GPS 2 Antenna Splitter (1) .
(1) Install protective caps on the three coaxial connectors (3) .
B. Remove two screws (2) that attach the GPS 2 Antenna Splitter (1) to the aircraft.
C. Remove the GPS 2 Antenna Splitter (1) from the aircraft.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: ALL POST MB 500-34-030
34-50-14
Page 401-Rem
Sep 30/20
