Eclipse EA500 User Manual

FLIGHT ENVIRONMENT DATA - ADJUSTMENT/TEST
AMM-34-10-00-071-801
1. General
A.
This task gives procedures to do an adjustment/test of the flight environment data
components.
NOTE: This test procedure complies with the requirements of 14 CFR Part 43 Appendix
E.
(1) Unless indicated differently, the adjustment/test procedures are the same for both left
and right sides.
(2)
Included are procedures for use of both the Barfield Pitot/Static Tester (Barfield,
DPS450) and the Barfield Pitot/Static Tester (Barfield, DPS500).
(3) After a replacement of the left and right Pitot/AOA probes, static ports, Air Data
Computers (ADCs), Standby Pitot/Static probe and Outside Air Temperature (OAT)
probes, do the test for each component shown in the table below.
Table 501. Component Test Matrix
Component to be Tested Test
Left and right ADCs Pitot and Static System Leak Test SUBTASK
AMM-34-10-00-071-701-001, Pitot and Static Verification Test
SUBTASK AMM-34-10-00-071-701-005 and Angle of Attack
Test SUBTASK AMM-34-10-00-071-701-004 and
AMM-24-00-00-071-801 – Electrical Power - Adjustment/Test,
SUBTASK AMM-24-00-00-071-701-005, Left and Right ADC
Test.
If software only is replaced, perform the following: Pitot
and Static Verification Test SUBTASK
AMM-34-10-00-071-701-005.
Left and right Pitot/AOA
probes
Pitot and Static System Leak Test SUBTASK
AMM-34-10-00-071-701-001, Angle of Attack Test SUBTASK
AMM-34-10-00-071-701-004 and AMM-30-30-00-071-801 –
Pitot and Static Anti-Ice System - Adjustment/Test.
If software only is replaced, perform the following: Pitot
and Static System Leak Test SUBTASK
AMM-34-10-00-071-701-001, and Angle of Attack Test
SUBTASK AMM-34-10-00-071-701-004.
Left and right Static ports Pitot and Static System Leak Test SUBTASK
AMM-34-10-00-071-701-001 and AMM-30-30-00-071-801 –
Pitot and Static Anti-Ice System - Adjustment/Test.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: NOTED
34-10-00
Page 501
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
