(3) On Transponder Test Set, IFR6000, select XPDR button. On CONFIG line, scroll
using up/down buttons to GENERIC MODE S. Press Return button.
(4)
On Transponder Test Set, IFR6000, select Run Test. Expected results are as follows:
• PASS, displayed on Transponder Test Set, IFR6000
• the tail number listed on the test set matches the aircraft tail number
NOTE: If the tail number is not displayed, refer to SUBTASK AMM-34-50-20-071-
A-701-002.
(5) Scroll to XPDR on Left PFD, Press the MODE softkey button to change the mode to
STBY.
(6)
On Transponder Test Set, IFR6000, select Run Test.
• Check that the NO REPLY message appears on upper section of Transponder
Test Set, IFR6000.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
PRE SB 500-99-002 AND SB 500-99-005
34-50-20
CONFIG A
Page 508
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
