(14) On the MFD, scroll to the SETUP tab, press the SENSOR Soft Key.
(15)
Set the ADC PFD source selection from AUTO to ADC 2.
(16) On the IFR 6000, press the XPDR button once. Once XPDR – ALT ENCODER is
displayed, press the SOURCE SELECT Soft Key until SOURCE - XPDR is displayed.
Press the RUN TEST Soft Key.
(17) Make sure that an altitude reported on IFR 6000 matches L PFD altitude indication
+/- 100 ft.
(18) On the MFD, set the ADC source back to AUTO.
(19) Set the WOW Box Switches to W-on-W (on-ground).
(20) Set XPDR 1 to STANDBY MODE.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
POST SB 500-99-002; AND 0105-0112,
0116-0119, 0121-0122, 0125-0262 PRE SB
500-99-005
34-50-20
CONFIG B
Page 522
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
