• “VS” = IN-AIR
(11)
On MFD, press SYS along bottom of MFD. Use the small lower knob on the MFD to
scroll to the SETUP page. On the SETUP page, press the SETTINGS softkey to
bring up the SETTINGS page. At the bottom of the SETTINGS page, check:
(a) The “REGISTRATION NO” number (alphanumeric) matches the “TAIL” number
(alphanumeric) displayed on the IFR 6000 (above).
(12) The “ICAO 24-BIT (OCT)” number matches the “AA” ICAO 24-bit code displayed on
the IFR 6000 (above).
NOTE: If the aircraft’s registration number and/or ICAO 24-bit (octal) number are not
present on the MFD’s SETTINGS page, the Aircraft Configuration File must
be updated, refer to AMM-31-40-00-051-801 – Aircraft Computer Systems -
Maintenance Practices. .
(13) On the MFD, scroll to the SETUP tab, press the SENSOR Soft Key. Set the ADC
PFD source selection from AUTO to ADC 2.
(14)
On the IFR 6000, press the XPDR button once.
(15) Once XPDR – ALT ENCODER is displayed, press the SOURCE SELECT Soft Key
until SOURCE - XPDR is displayed. Press the RUN TEST Soft Key.
(16) Make sure an altitude reported on IFR 6000 matches L PFD altitude indication +/-
100 ft.
(17) On the MFD, set the ADC source back to AUTO.
Set the WOW Box Switches to W-on-W (on-ground).
(19) Set XPDR 2 to STANDBY MODE.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001-0104, 0113-0115, 0120, 0123-0124
POST SB 500-99-002; AND 0105-0112,
0116-0119, 0121-0122, 0125-0262 PRE SB
500-99-005
34-50-20
CONFIG B
Page 525
Sep 30/20
