Eclipse EA500 - Page 55

5141821A
14
A
RH
PITOT/AOA
PROBE
A
4
13, 14
7
4
AIRCRAFT
STRUCTURE
7
13
7
11
10
8
12
B
B
Pitot/AOA Probes - Removal/Installation
Figure 401 (Sheet 4 of 5)
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: ALL, POST MB 500-34-027 AND MB
500-34-028
34-10-10
CONFIG C
Page 407-Inst
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
