STORMSCOPE - ADJUSTMENT/TEST
AMM-34-40-50-071-B-801
1. General
A.
This task gives the procedures to perform the Adjustment/Test for the Lightning Detection
System (LDS). The LDS on the aircraft is referred to by it’s trademark name
Stormscope®. The Stormscope computer is on the options rack in the maintenance bay.
The Stormscope antenna is mounted internally under the upper over fin fairing on top of
the horizontal stabilizer.
B. Testing Matrix:
(1) If the 331 DT - Upper Overfin Fairing is removed, perform SUBTASK
AMM-34-40-50-071-B-701-001.
(2) If the 331 DT - Upper Overfin Fairing is installed, perform SUBTASK
AMM-34-40-50-071-B-701-002.
2.
Equipment and Materials
Table 501. Special Tools and Equipment
Name and Part Number
External Battery Pack, (PowerVamp, Model APS1500
WX-PA Portable Analyzer (L3 Com P/N 78-8060-5791-1)
3. Job Set-Up
SUBTASK AMM-34-40-50-071-B-921-001
A.
Make aircraft safe for maintenance. Refer to AMM-20-00-01-051-801 – Make Safe For
Maintenance.
B. Connect an External Battery Pack to the aircraft EXTERNAL POWER RECEPTACLE
and turn on power. Ensure the green EXT POWER light on the IPL is on. But do not turn
on aircraft’s power. Refer to AMM-24-40-00-051-801 – External Power - Maintenance
Practices.
C. Remove (if necessary) 331 DT - Upper Over Fin Fairing. Refer to
AMM-55-10-12-001-801 – Overfin Fairing - Removal.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001 - 0008, 0010 - 0050, 0052, 0054 -
0267 POST SB 500-31-024
34-40-50
CONFIG B
Page 501
Sep 30/20
