(11) Key the pilot’s Comm mic switch (transmit on VHF 1 Comm) repeatedly.
(a)
Verify no strike data appears on the PFDs as a result of keying the VHF 1
transmitter.
(12) On either PFD, tune the VHF 2 COMM radio to a test frequency (e.g., 123.450 MHz).
(a) Select COM 2 as the ACTIVE radio.
(13) Key the co-pilot’s Comm mic switch (transmit on VHF 2 Comm) repeatedly.
(a) Verify no strike data appears on the PFDs as a result of keying the VHF 2
transmitter.
(14) Verify aircraft is positioned so that it can be freely turned 45° (± 5°) clockwise (to the
right).
(a) Make sure area around aircraft is clear.
(b) Make sure that WX-PA tester can be moved with the aircraft.
(c) Make sure adequate cable is deployed from the external power cart to allow the
aircraft to turn 45° to the right.
(15) Power up the WX-PA Portable Analyzer unit.
• After the WX-PA completes self-test, the MODE MENU will be displayed.
(16) On the WX-PA, select “Continuous Out” on the MODE MENU, then press the MENU/
ENTR button once (so that WX-PA indicates “PAUSED” and not “RUNNING”).
(17) On the WX-PA, press the FLAPS/A button to select top mount antenna configuration.
(18) On the WX-PA, select a cardinal bearing of 0° and a range of 55 NM.
Refer to TEST - 1 in Table 502.
• Use F1 and F2 buttons to adjust range and the F3 and F4 buttons to adjust
bearing.
(19) On the WX-PA, with “Continuous Out” still selected on the MODE MENU, press the
MENU/ENTR button once so that WX-PA indication changes from “PAUSED” to
“RUNNING”.
(20) On the PFD, press the STRIKE CLEAR LSK.
• Strike data cleared from PFDs, then begins building again.
EA500 Aircraft Maintenance Manual — 06-117751
Temporary Revision No. 34-21
EFFECTIVITY: 0001 - 0008, 0010 - 0050, 0052, 0054 -
0267 POST SB 500-31-024
34-40-50
CONFIG B
Page 503
Sep 30/20
© 2020 Eclipse Aerospace, Inc.
