TECHNICAL DATA
HCAT TE - HCAN TE
21English 04/03
AI
Size HCAN TE 0071 0091 0101 0121
Gas line connection
mm-inch
22,22-7/8” 22,22-7/8” 28 28
Liquid line connection
mm-inch
15,90-5/8” 15,90-5/8” 18 18
No.of fansN°1122
Air flow m3/h 9800 9800 14000 14000
Cooling capacity (1) kW 19,6 24,5 28,5 35,0
Compressor absorbed power (1) kW 6,0 7,3 8,3 10,3
Total absorbed power (1) kW 6,7 8,0 9,1 11,1
Factory charge of R407c refrigerant (3) Kg 7,5 7,9 11,5 11,9
32 MMM POE oil Kg 4,0 4,0 4,0 4,0
Operating weight Kg 237 240 304 306
Compressor type Scroll Scroll Scroll Scroll
No. of compressors N° 1111
No. of circuits N° 1111
Power steps N° 1111
Heating capacity (2) kW 22,8 29,0 33,1 41,3
Compressor absorbed power (1) kW 6,0 7,2 8,3 10,2
Total absorbed power (1) kW 6,7 7,9 9,1 11,0
Dimension (A) mm 1450 1450 1450 1450
Dimension (B) mm 1200 1200 1700 1700
Dimension (C) mm 550 550 550 550
Sound pressure level (4) dB(A) 65 65 65 65
(1) Saturated intake temperature: = +4°C. condenser air intake = +35°C. (4) At 1 metre in open field.
(2) Condensing point = +50°C. evaporator air in: = +7°C., 85% RH.
(3) Content for use with corresponding HEN SE and valid for five metres of piping.
Cooling capacity (1) kW 5,3 6,2 7,9 9,5 11,9 14,4 17,5 20,5 25,7 29,8 36,7
Compressor absorbed power (1) kW 1,7 2,1 2,5 2,9 3,4 4,2 4,9 6,3 7,7 8,9 10,9
Factory charge of R407C refrigerant (3) Kg 2,1 2,3 2,3 2,9 3,6 3,8 5,1 5,8 7,2 10,4 10,8
32 MMMPOE oil Kg 1,1 2 2 1,1 2 2 1,6 4444
Operating weight Kg 74 77 79 87 102 116 123 225 228 288 291
Compressor type Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll Scroll
No. of compressors N° 11111111111
No. of circuits N° 11111111111
Power steps N° 11111111111
No.of fansN°11111221122
Min. rotation speed g/m 400 430 430 430 430 420 420 430 430 310 310
Max. rotation speed g/m 820 870 870 870 870 860 860 870 870 620 620
Max. air flow m3/h 3000 3200 3200 3500 3400 6400 5800 9800 9800 14000 14000
Width mm 900 900 900 900 900 900 900 1450 1450 1450 1450
Dimension height mm 740 740 740 990 990 1240 1240 1200 1200 1700 1700
Dimension depth mm 370 370 370 370 370 420 420 550 550 550 550
Liquid connection
mm/inch 9,52-3/8" 9,52-3/8" 9,52-3/8" 9,52-3/8" 9,52-3/8" 12,7-1/2" 12,7-1/2" 15,9-5/8" 15,9-5/8" 18 18
Gas connection
mm/inch 15,9-5/8" 15,9-5/8" 15,9-5/8" 15,9-5/8"
19,05-3/4" 19,05-3/4" 19,05-3/4" 22,2-7/8" 22,2-7/8" 28 28
Sound pressure level (4) dB(A) 57 58 58 58 58 61 60 65 65 65 65
Size HCAT TE 0011 0021 0025 0031 0041 0051 0061 0071 0091 0101 0121
(1) Saturated intake temperature: +4°C, condenser air in: 35°C (3) Content for use with corresponding HED/N SE and valid for five metres of piping
(2) Condensing point = +50°C, evaporator air in: +7°C (4) At 1 metre in open field
N.B. Max outside air temperature 43°C
