Eco HCAT TE 0121 - Dimensional Drawings

Ø35
8
NM
ML
W4
W1
W3
W2
E
6
7
C
G
F
5
EG
5
6
7
F
UNITÁ 101-121
UNIT 101-121
H==
I==
2 1
3
4
D
A
B
SOLLEVAMENTO
LIFTING
N
W1 W2
W4 W3
M
LM
G
C
E
F
=I=
B
A
O
= H =
W1 83 84 106 107
W2 41 41 52 52
W3 38 38 49 49
W4 75 77 97 98
TOT 237 240 304 306
Weight distribution HCAN TE 0071 0091 0101 0121
A 900 900 900 900 900 900 900 1450 1450 1450 1450
B 740 740 740 990 990 1240 1240 1200 1200 1700 1700
C 370 370 370 370 370 420 420 550 550 550 550
D-------1507 1507 1507 1507
E 91,5 91,5 91,5 91,5 91,5 91,5 91,5 93 93 45 45
F 102 102 102 102 102 102 102 140 140 153 153
G 202 202 202 202 202 202 202 240 240 100 100
H 400 400 400 400 400 450 450 497 497 497 497
I 580 580 580 580 580 580 580 1477 1477 1477 1477
O 430 430 430 430 430 480 480 ----
Dimension 0011 0021 0025 0031 0041 0051 0061 0071 0091 0101 0121
Functional distances 0011 0021 0025 0031 0041 0051 0061 0071 0091 0101 0121
L 900 900 900 900 900 900 900 900 900 900 900
M 150 150 150 200 200 200 200 400 400 400 400
N 600 600 600 600 600 600 600 600 600 600 600
Weight distr. HCAT TE 0011 0021 0025 0031 0041 0051 0061 0071 0091 0101 0121
W1 29 30 31 34 38 41 46 78 79 101 102
W2 12 12 13 14 16 19 21 40 40 50 50
W3 10 11 10 12 15 17 18 38 38 46 46
W4 23 24 25 27 33 39 38 69 71 91 93
TOT 74 777987102116 123 225 228 288 291
DIMENSIONAL DRAWINGS
HCAT TE - HCAN TE
5English 04/03
I
1 compressor
2 condensing/evaporating
coil
3 electrical panel
4 axial-flow fans
5 liquid line connection
6 gas line connection
7power line input
(0071÷0121)
8 lifting holes
Models 0071-0091 are fitted
with the top fan only.
MODELS 0011÷0061
MODELS 0071÷0121
