Ecom j2kn pro - Page 27

ecom-J2KN
pro
Page 27
The setting for “Printer” can be changed as follows:
-select menu point and confirm with <OK>
-select desired setting with the curser keys
-confirm with <OK>
The setting for “Store” can be changed as follows:
select menu point and confirm with <OK>
activate storage function with <F1>
deactivate storage function with <F4>
By ‘Start measurement’ / <OK> the
evaluation of the measurement values
will be started. On the display the actual
mean values will be shown (will be up-
dated with new measurement values /
switch to the actual values with cursor
keys <up/down>). It is possible to scroll
through the values with the cursor keys
<right/left>. With <F2> you can inter-
rupt and with <F4> stop the measure-
ment.
After finishing the measurement time a protocol of the results with all
mean values can be printed (key <Print>).
O2 3.2 %
CO2 13.1 %
CO 0 ppm
Eff. 92.5 %
Losses 7.5 %
Exc. air 1.18
T.Gas 184 °C
T.Air 20 °C
Mean value 25.11.07
15:59 min
