1.2. Control module
ESC key
(quit/
escape menu)
In the input mode,
the keys are used
for numerical inputs
OK key
(confirm selec-
tion)
Cursor keys
(Up/Down/Right/
Left/Scroll)
Measurement
values record-
ing
Print key
(access to
printing menu)
Switch ON/OFF
control module
Display
backlit
ON/OFF
Function keys
(function shown on display)
Slot for Multi-
Media-Card
Graphics
display
Connection
USB
Connection
keyboard
Socket for connection
cable by wire
transfer basic
Keyboard control module
Connection air
temperature
