1. Instrument design
1.1. Basic module
Connection
air
temperature
Connection
gas tem-
perature
Condensate
trap with fine
dust filter
Connection
gas hose
Connection
draught
Connection
pressure
Con
nection
condensate
evacuation
Integral
printer
Filter for
IR bench
Control
module
(see next page)
Connection mains
power plug
with fuse
(630 mA / 250 V)
Info display
(see chap-
ter 11.)
Basic
ON / OFF
Analogue
inputs
(Option)
Connection
heatet probe
(Option)
Connection
AUX
SO2/NOx-
filter for
CO sensor
Connections
pitot tube
(Option)
Cable socket
by wire transfer
basic / control
modules
