7. Installaon of the faucet.
7.1. To install drinking water faucet (3) drill 12.5
mm (1/2”) diameter hole for single way tap in a
convenient locaon at the sink or countertop.
Cauon! metal shavings can damage your
unit, remove them carefully as soon as you
have drilled the hole. If the mounng surface
is ceramic or stone, you may need a special
carbide drill.
Mount the faucet on the sink or countertop as
shown in the gure. Upper gasket, gasket ring,
below gasket and installaon knob on the faucet
shank must x the faucet rmly on the surface.
7.2 Push the direct quick coupling as deeply as
possible to the boom of the faucet’s inlet water
threaded pipe and insert the xing clip.
7.3 Aer the faucet is installed, insert the other
end of the 1/4” white tube of pure water pipe
connected to the rack into the quick connecon
of the faucet and insert the xing clip.
7.4 Take the faucet aviaon connector and insert
it into the special connector on the connecon
panel in the required direcon, and x it by
screwing it with a plasc ring.
Data interface
Aviaon interface
Faucet body
Upper gasket
Countertop
Gasket ring
Below gasket
Installaon knob
Inlet water threaded pipe
Direct quick coupling
1/4” quick coupling
lock plate
1/4” PE Pipe
