36
Introducing the Motherboard
Soft-Off By PWR-BTTN (Instant Off)
Under ACPI (Advanced Configuration and Power management Interface) you can
create a software power down. In a software power down, the system can be resumed
by Wake Up Alarms. This item lets you install a software power down that is con-
trolled by the power button on your system. If the item is set to Instant-Off, then the
power button causes a software power down. If the item is set to Delay 4 Sec, then
you have to hold the power button down for four seconds to cause a software power
down.
Resume by PCI/PCI-E/Lan PME (Disabled)
These items specify whether the system will be awakened from power saving modes
when activity or input signal of the specified hardware peripheral or component is
detected.
Resume By USB (S3) (Disabled)
This item allows you to enable/disable the USB device wakeup function from S3/S4
mode.
Resume By PS2 KB (S3) (Disabled)
This item enable or disable you to allow keyboard activity to awaken the system
from power saving mode.
Resume By PS2 MS (S3) (Disabled)
This item enable or disable you to allow mouse activity to awaken the system from
power saving mode.
PWRON After PWR-Fail (Power Off)
Resume On Ring (Disabled)
This item enables your computer to automatically restart or return to its last oper-
ating status.
The system can be turned off with a software command. If you enable this item, the
system can automatically resume if there is an incoming call on the Modem/Ring, or
traffic on the netwwork adapter. You must use an ATX power supply in order to use
this feature.
Press <Esc> to return to the main menu setting page.
Resume By RTC Alarm (Disabled)
The system can be turned off with a software command. If you enable this item, the
system can automatically resume at a fixed time based on the system’s RTC (realtime
clock). Use the items below this one to set the date and time of the wake-up alarm.
You must use an ATX power supply in order to use this feature.
