Introducing the Motherboard
Advanced Setup
This page sets up more advanced information about your system. Handle this page
with caution. Any changes can affect the operation of your computer.
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Advanced Setup
Thermal Management Enabled
TM Status TM1/TM2
Limit CPUID MaxVal Disabled
Enhanced Halt (C1E) Enabled
Intel XD Bit Disabled
Intel EIST Enabled
Quick Power on Self Test Enabled
Boot Up Numlock Status On
APIC Mode Enabled
1st Boot Device Hard Drive
2nd Boot Device CD/DVD
3rd Boot Device 1st FLOPPY DRIVE
Removable Drives Press Enter
Boot Other Device Yes
BIOS Protect Disabled
For the processorites
CPUID belows 0F41h.
TM2 only can be enable
under below setting.
1. Freq.>=3.6GHz FSB800
2. Freq.>=2.8GHz FSB533
Help Item
f
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Thermal Management (Enabled)
Quick Power on Self Test (Enabled)
Enable this item to shorten the power on testing (POST) and have your system start
up faster. You might like to enable this item after you are confident that your system
hardware is operating smoothly.
Limit CPUID MaxVal (Disabled)
Enhanced Halt (C1E) (Enabled)
Intel XD Bit (Disabled)
Intel EIST (Enabled)
Use this item to enable or disable the Max CPU ID value limit. When supports
Prescott and LGA775 CPUs, enables this to prevent the system from “rebooting”
when trying to install Windows NT 4.0.
This item enables or disables enhanced halt.
This item displays CPU’s temperature and enables you to set a safe temperature to
Prescott CPU.
TM Status (TM1/TM2)
This item displays CPU Monitor status.
This item allows users to enable or disable the Intel XD bit.
This item allows users to enbale or disable the EIST(Enhanced Intel SpeedStep
Technology) function. This item shows only if the CPU supports EIST.
To Next Page
