ECS GF7050VT-M5 User Manual

1
Introducing the Motherboard
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the GF7050VT-M5 motherboard. This motherboard is a
high performance, enhanced function motherboard designed to support the LGA775
socket for Intel
®
Core
TM
2 Quad*/Core
TM
2 Duo/Pentium
®
D*/Pentium
®
4*/Celeron
®
D processors for high-end business or personal desktop markets.
This motherboard is based on NVIDIA
®
MCP73V for best desktop platform solution.
MCP73V is a single-chip, highly integrated, high performance Hyper-Threading
peripheral controller, unmatched by any other single chip-device controller. This
motherboard supports up to 4 GB of system memory with
Single Channel DDR2 667/
533 (Over spec up to 800*) MHz. High resolution graphics via a PCI Express x16
slot, 8 USB 2.0 ports (4 USB ports and 2 USB 2.0 headers support additional 4 USB
ports) and SATA support with RAID function.
There is an advanced full set of I/O ports in the rear panel, including PS/2 mouse and
keyboard connectors, COM, one VGA port, four USB ports, one LAN port and audio
jacks for microphone, line-in, and line-out. This motherboard is designed in a Micro
ATX form factor using a four-layer printed circuit board and measures 244 mm x 194
mm.

ECS GF7050VT-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Core 2 Duo, Intel Core 2 Quad
CPU fan connector	Yes
Number of SATA connectors	4
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Certification	ROHS
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
BIOS memory size	64 Mbit
Maximum graphics card memory	256 MB
RAID levels	0, 1

Weight and Dimensions

Depth	194 mm
Width	244 mm
