29
Introducing the Motherboard
For the purpose of better product maintenance, the manufacture reserves
the right to change the BIOS items presented in this manual. The BIOS setup
screens shown in this chapter are for reference only and may differ from the
actual BIOS. Please visit the manufacture’s website for updated manual.
Standard CMOS Setup
This option displays basic information about your system.
Date Wed 10/10/2007
Primary IDE Master Not Detected
Primary IDE Slave Not Detected
SATA 1 Not Detected
SATA 2 Not Detected
SATA 3 Not Detected
SATA 4 Not Detected
IDE BusMaster Enabled
Drive A: 1.44 MB 3
1
/
2
”
Help Item
CMOS Setup Utility -- Copyright (C) 1985-2007, American Megatrends, Inc.
Time 00 : 02 : 56
User [ENTER], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Date.
Standard CMOS Setup
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
f
f
f
f
f
f
Date & Time
The Date and Time items show the current date and time on the computer. If you are
running a Windows OS, these items are automatically updated whenever you make
changes to the Windows Date and Time Properties utility.
Primary IDE Master/Slave, SATA 1~4
f
Your computer has one IDE channel which can be installed with one or two devices
(Master and Slave). In addition, this motherboard supports four SATA channels and
each channel allows one SATA device to be installed. Use these items to configure
each device on the IDE channel.
CMOS SETUP UTILITY – Copyright (C) 1985-2007, American Megatrends, Inc.
Primary IDE Master
Primary IDE Master
Type Auto
LBA/Large Mode Auto
Block (Multi-Sector Transfer Auto
PIO Mode Auto
DMA Mode Auto
S.M.A.R.T Auto
32Bit Data Transfer Enabled
Help Item
Select the type
of device connected
to the system.
Device : Not Detected
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Optimized Defaults
F1: General Help
To Next Page
