Introducing the Motherboard
Frequency/Voltage Control
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have in-
stalled in your system.
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Frequency/Voltage Control
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Auto Detect DIMM/PCI CIK Enabled
CPU BSEL Select Auto
PCIE Spread Spectrum Disabled
CPU Spread Spectrum Disabled
System Clock Mode Auto
Memory Voltage +1.90V
NB Voltage 1.349V
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
CPU BSEL Select (Auto)
These items is used to select the CPU/LDT BSEL.
Manufacturer: Intel
Ratio Status: Unlocked (Min:06, Max:12)
Ratio Autual Value: 12
Manufacturer (Intel)
These items show the brand of the CPU installed in your system.
Ratio Status/Ratio Actual Value
These items show the Locked ratio status and the actual ratio of the CPU installed in
your system.
Memory Voltage (+1.90V)
This item allows users to adjust the DDR memory voltage.
PCIE Spread Spectrum (Disabled)
This item, when enabled, can significantly reduce the EMI (Electromagnetic Inter-
ference) generated by the PCIE.
[Auto] Set FSB & Memory
clock automatically.
[Linked] Allows Memory
and FSB to overclock pro-
portionally.
[Manual] Enter FSB and
Memory clock manually.
CPU Spread Spectrum (Disabled)
If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
System Clock Mode (Auto)
This item determines the current and target FSB and memory speed when the
system is undertaking the best performance.
